Compact Cap Embroidery Machine
التوفر: موجود في المخزن
Model: SINSIM- C904
Needles : 9 Needles
Heads Number : 4
- Suitable for flat embroidery, cap embroidery and finished garments embroidery. Simple & fast change Cap frames, Slopwork frames and Flat frames exchange to reach Cap embroidery, finished garments embroidery and flat embroidery 3 kinds embroidery way.
- The machine has multi-heads and needles, can embroider several colors stitch flat designs at the same time, with auto trimmer function.
- Machine will auto stop and show the thread breakage head position if the thread break or the upper and udder thread used up when in the embroider.
- The function of repair embroider: to individual repair embroider design for which one need.
- Attachment the sequin device (in first or last needle), have F3F5F7F9 size, can embroider sequin design and combine flat embroider together.
- Attachment the Boring Device(in first needle) can embroider the boring designs.
- According the device attachment position, several kinds of different device can attachment in the same flat head and combine another function embroider in the same design.
- 5inch,8inch,10inch touch monitor computer selectable. Modern Design of operating panel, USB input port ,Color LCD display showing real time stitching ,Pre-sew design trace capable Emergency stop.
- High Speed Up to 850RPM.
- Color-Change Mode: Step Color-change , Automatic Color Change. Auto color change according the design when in embroider.
- Thread Trimming system: Automatic Thread Trimmer, Solenoid thread holding, step motor thread trimming and catching.
- Needle Position Detecting : Rheostat . The machine has multi-heads and needles, can embroider several colors stitch flat designs at the same time, with auto trimmer function.
- Thread Break Detecting : Thread break detection ,Thread take-up spring or chopping wheel . Machine will auto stop and show the thread breakage head position if the thread break or the upper and udder thread used up when in the embroider.
- Memory: 2 Million , Design Number :200. After the design file input computer can keep forever, the memory storage up to 2,000,000 stitches and store 200 samples.
- Language: Chinese, English, Turkish, French, Spanish, Portuguese
- Data Transfer Floppy Disk: Pattern input/output support USB updating.
- Network Function: Support multi-machine network, data transfer, state monitoring, operating though network.
- 270�wide cap frame unit
- Electricity: 220V/50Hz ,380V/50HZ available
- The pantograph driver used AC step motor, let the movement fast and smooth.
- Choose different modal frames can embroider in different products such as Slopwork, Cap ,gloves ,cuffs and normal flat etc .
- Software limited spacing function, Convenient Slopwork and Cap embroider.
- Automatic control embroidery, no need manual operate, make the embroidery robotization and standardization.
- Vast flexibility: With Standard International DST.DSB and ZSK design format.
- USB connection: Can through computer connection input and output design.
- 2 x Shirt Front Round Hoop 9 cm (3.5")
- 2 x Shirt Front Round Hoop 20 cm (9")
- 2 x Shirt Front Round Hoop 12 cm (4.7")
- 2 x Jacket Back Square Hoop 29 x 29 cm (12" x 12")
- 2 x Shirt Front Round Hoop 15 cm (5.9")
Cap Attachments Included:
Table and stand with wheels for easy moving around.
Exploded View of Machine
Automatic Bobbin Winding Machine
Air Compressor(If Need)
[Example of model code]
SINSIM-C (a), 9 (b), 04 (c)
Contents of model code :
