Super Multi-Head Machine

التوفر: موجود في المخزن

Technical Parameter


Model : SINSIM-SF
Needles : 4 Needles
Heads Number : 84 or 56&



Function:

The various Embroidery Machines of "SINSIM" brand widely apply batch process in the Toy,childrens wear,Sweater,Underclothes,Bedding, fashional field, handbag, wedding Dress, Shoes/Hat ,Curtain, Accessories, Top Grade Art ware etc.and with excellent performance.

Main Function:

- The machine has multi-heads and multi-needles, can embroider several chain stitch flat designs at the same time and have the auto trimmer function.

- 5inch,8inch,10inch touch monitor computer selectable. Modern Design of operating panel, USB input port ,Color LCD display showing real time stitching ,Pre-sew design trace capableEmergency stop

- Color-Change Mode: Step Color-change , Automatic Color Change. Auto color change according the design when in embroider.

- Thread Trimming system: Automatic Thread Trimmer, Solenoid thread holding, step motor thread trimming and catching.

- Needle Position Detecting : Rheostat . The machine has multi-heads and needles, can embroider several colors stitch flat designs at the same time, with auto trimmer function.

-Thread Break Detecting : Thread break detection ,Thread take-up spring or chopping wheel . Machine will auto stop and show the thread breakage head position if the thread break or the upper and udder thread used up when in the embroider.

- Memory: 2 Million , Design Number :200. After the design file input computer can keep forever, the memory storage up to 2,000,000 stitches and store 200 samples

- Language: Chinese, English, Turkish, French, Spanish, Portuguese

- Data Transfer Floppy Disk: Pattern input/output support USB updating.

- Network Function: Support multi-machine network, data transfer, state monitoring, operating though network.

-Electricity: 220V/50Hz ,380V/50HZ available

Main configuration:

-Dahao electric system, 322 5 inch monitor (without trimmer)/328 ( with trimmer),And you can choose top grade computer like C18/C88/366 Computer.

-Main motor :Dahao servo , Panasonic Servo ,Fuji Servo ,Sanyo Servo available.

-X/Y Driver: All servo or Stepping Motor available.

-Origian Japanese Rotary Hook

-New style Liner driver

-Automatic trimmer device( Adapting)

-Needles: 3/4 Needles ,Heads: 56 -84 Heads, Embroidery Space: X /150-1100mm,Y/300-1200mm.

Accessories Included :

- Table Support and Washer of machine foot

- Exploded View of Machine

- Operation Manual

- Tool Kit.

- Automatic Bobbin Winding Machine

- Air Compressor (If Need)



[Example of model code]



SINSIM-MF (a), 4(b), 84(c)
Contents of model code :
a=Model Name
