Main Features

SINSIM 3 in 1 mixed machine has additional feature besides flat and sequins


All types of embroidering: taping: taping 1 , taping 2 and frill embroidering; Zig-zag: Z1~Z6;
Embroidery can be different by adjusting the range of oscillation;
Combined embroidering: flat, sequin, Z1~Z6, taping, coiling and frill embroidering;
Adjusting the coiling density automatically: Coiling can be divided into left coiling and right coiling according to different core thread being used. The coiling density is adjustable by changing coiling rate.
Function of coiling tracking: it enables the coiling head to track that the density if coiling seldom is not average in different angle and the tensions of upper threads are not the same. Due to this function, the quality of coiling enters a new lever.
Automatic Speed control could be accommodated in different embroidery way according to the pin mark, like flat embroidery could reach max 850 rpm, tapping, zigzag, cording embroidery could reach max 600 rpm, and coiling embroidery could reach 500 rpm.
Embroidery type could be adjusted by your order. Flat and coiling embroidery could be changed by manual or automatic operation. Embroidery type could be selected by the operation panel. Combination of embroidery type is various and acceptable by accessory addition.
Embroidery type could be adjusted by your order. Flat and coiling embroidery could be changed by manual or automatic operation. Embroidery type could be selected by the operation panel. Combination of embroidery type is various and acceptable by accessory addition.
Embroidery type could be adjusted by your order. Flat and coiling embroidery could be changed by manual or automatic operation. Embroidery type could be selected by the operation panel. Combination of embroidery type is various and acceptable by accessory addition.
Embroidery type could be adjusted by your order. Flat and coiling embroidery could be changed by manual or automatic operation. Embroidery type could be selected by the operation panel. Combination of embroidery type is various and acceptable by accessory addition.
Manual or automatic presser foot elevate function are also adapted, that convenient to change embroidery frame and cloth. Product is artistic and stable.
Main functions:

- 5inch, 8inch, 10inch, touch monitor computer selectable. Modern Design of operating panel,USB input port ,Color LCD display showing real time stitching,Pre-sew design trace capable Emergency stop.

- Color-Change Mode: Step Color-change, Automatic Color Change. Auto color change according the design when in embroider.

- Thread trimming system: Automatic Thread Trimmer, Solenoid thread holding, step motor thread trimming and catching.

- Needle Position Detecting: Rheostat. The machine has multi-heads and needles, can embroider several colors stitch flat designs at the same time, with auto trimmer function.

- Thread Break Detecting: Thread breaks detection, Thread take-up spring or chopping wheel. Machine will auto stop and show the thread breakage head position if the thread break or the upper and udder thread used up when in the embroider.

- Memory: 2 Million, Design Number :200. After the design file input computer can keep forever, the memory storage up to 2,000,000 stitches and store 200 samples.

- Language: Chinese, English, Turkish, French, Spanish, Portuguese

- Data Transfer Floppy Disk: Pattern input/output support USB updating.

- Network Function: Support multi-machine network, data transfer, state monitoring, operating though network.

- Electricity: 220V/50Hz ,380V/50HZ available.

Main configuration:

- Dahao electric system, 322 5 inch monitor (without trimmer)/328 ( with trimmer),And you can choose top grade computer like C18/C88/366 Computer.

- Main motor :Dahao servo , Panasonic Servo ,Fuji Servo ,Sanyo Servo available.

- X/Y Driver: All servo or Stepping Motor available.

- Origian Japanese Rotary Hook

- New style Liner driver

- Automatic trimmer device( Adapting)

- Needles: 3/4 /6/9/12/15Needles ,Heads: 1-56 Heads, Embroidery Space: X /150-1100mm,Y/300-1200mm.

Accessories Included:

- Table Support and Washer of machine foot

- Exploded View of Machine

- Operation Manual

- Tool Kit.

- Automatic Bobbin Winding Machine

- Air Compressor (If Need)
